Homogenisers

This brand new batch type emulsifier is fitted with a Slotted Disintegrating Head. It is used for many applications, but is very useful for the disintegration of fibrous materials such as animal and vegetable tissue. It is also used as well for the disintegration and solubilisation of elastic materials such as rubbers and polymers. Working Capacity: 200-800L @ 2,800RPM Motor Size: 7.5kW 3 Phase

Scorpion electric motor Type: TAI 30L1-2 3ph, 415V, 2.2kW, 3HP, 4.13A

NS2006L is a standalone fully equipped laboratory unit for food & beverage, pharmaceutical, biotechnology, cosmetic, chemical testing or small production, featuring the performances of the industrial scale homogenizers. Max press: 100MPa Rated flow: 80 dm3/hr Motor power: 5.5kW Net weight: 400 kg Gross weight: 520 kg Lubricating and cooling water: 40 L/h Lubricating oil ISO VG 150: 1.5L Feeding h

The unhomogenized product enters the valve area at high pressure and low velocity. As the product enters the adjustable, close clearance area between the valve and seat, there is a rapid increase in velocity with a corresponding decrease in pressure. The intense energy release causes turbulence and localized pressure differences, which will tear apart the particles. The homogenized product impinge

Working Principle The product is pumped under high pressure into the homogenizing device. In the device the product is forced through a small annular gap where the pressure transforms into high velocity. Extreme turbulence and cavitation effectively reduce the size of liquid droplets and solid particles. Application High-pressure homogenization of emulsions and suspensions. Available als

This is a single-stage, 3 piston, hydraulically operated homogenizer. Max operating pressure is 50 bar. Fields of application: Dairy Food Cosmetic Chemical Pharmaceutical Biotech products Max GPH : 1370 Max LPH : 5200 Max PSI : 2175 Max Pressure : 50 Bar The Rannie 55 / Gaulin 55 homogeniser, a positive displacement triplex, reciprocating plunger pump, is fitted with an application sp

<Specifications> Motor Size: 11kW 3 Phase Contact material SUS316 Batch Emulsifier Length: 860 mm

This unit is a full pilot process plant. It comprises many items amongst which are: * Control panel and starter. * Oil phase - Self heated for delivering oil at pre-determined temperature to the vacuum homogenizing vessel. * Pump to deliver oil to jacket of vacuum vessel * Vacuum pump to pull vacuum in vacuum vessel * Vacuum vessel fitted with the following items: Homogenizer: kW: 0.55,Hz

Specifications: Inlet Diameter : 63 mm Outlet Diameter : 51mm Rated Capacity : 0.5m3/h Motor: 15kW Can get down to 300 - 400 micron particle size - depending on product and flowrate.

This brand new batch type emulsifier is fitted with a Slotted Disintegrating Head. It is used for many applications but is very useful for the disintegration of fibrous materials such as animal and vegetable tissue. It is also used as well for the disintegration and solubilisation of elastic materials such as rubbers and polymers. Motor Size: 11kW 3 Phase Contact material SUS316 Batch Emul

This s/s SANMARU Homogenizer was previously used in a food factory. No of Stages: Single Capacity: 1000 - 1500L/hr Pressure: 3000 psi (to be verified) Motor Size: 11kW, 6 pole Fitted with a speed. variator YOM: 2007 Ball Valve Type

This s/s SANMARU Homogenizer was previously used in a food factory. No of Stages: Single Capacity: 1000 - 1500L/hr Pressure: 3000 psi (to be verified) Motor Size: 11kW, 6 pole Fitted with a speed. variator YOM: 2007 Ball Valve Type

<Specifications> Flow Rate: 0 - 15 cbm//hr Head Height: Max 20m Speed: 2,900 rpm Screen Sizes: 4mm (Different Size Available - Second Screen Onward at Additional Cost) Inlet: 2.5" with Reducer & Tri-Clover Fittings to 2" for Easy Connection with Lobe Pump Outlet: 2" Motor Size: 7.5kW

IOPAK TRS1 Series. Model TRL1/100-2.2 H In Line High Shear Dispersion Emulsifier This is a brand new fully stainless steel toothed colloid mill/emulsifier. It has a high shear dispersing action and is used for the continuous production or closed circuit treatment of fine material. Typical products to be emulsified, might include: Mayonnaises, sauces, emulsions, lotions, creams, purees etc.

IOPAK TRS1 Series. Model TRS/165-7.5 H In Line High Shear Dispersion Emulsifier This is a brand new fully stainless steel toothed colloid mill/emulsifier. It has a high shear dispersing action and is used for the continuous production or closed circuit treatment of fine material.Typical products to be emulsified, might include: Mayonnaises, sauces, emulsions, lotions, creams, purees etc RS/165

This brand new emulsifier is fitted with three sets of stators, rotors (or impellers) and chambers or cavities. It makes beautiful glossy mayonnaise, sauces and emulsifications.- - 3 Stage particulate reduction using 3 separate in-line rotor/stator units - Various gap sizes for particulate reduction can be set by changing the stator and rotor - This type of machine is particularly suitable fo

This brand new batch type emulsifier is fitted with a Slotted Disintegrating Head. It is used for many applications, but is very useful for the disintegration of fibrous materials such as animal and vegetable tissue. It is also used as well for the disintegration and solubilisation of elastic materials such as rubbers and polymers. Working Capacity: 200-800L @ 2,800RPM Motor Size: 7.5kW 3 Phase

This brand new batch type emulsifier is fitted with a Slotted Disintegrating Head. It is used for many applications but is very useful for the disintegration of fibrous materials such as animal and vegetable tissue. It is also used as well for the disintegration and solubilisation of elastic materials such as rubbers and polymers. Working Capacity: 50-100L @ 2,800RPM Motor Size: 2.2kW 3

This is a brand new fully stainless steel toothed colloid mill/emulsifier. It has a high shear dispersing action and is used for the continuous production or closed circuit treatment of fine material. Typical products to be emulsified, might include: Mayonnaises, sauces, emulsions, lotions, creams, purees etc Capacity: Max 5 Cub M/Hr (Water - conditions may vary) Pump suction pressure
